4K@60Hz Bi-Directional 2-Port HDMI Switch (207850)

The Manhattan 4K Bi-Directional 2-Port HDMI Switch with a built-in booster allows flexible switching between HDMI devices. You can share one 4K UHD source between two UHD displays or connect two 4K UHD sources to one UHD display and easily switch between them.

Contact to Seller
  • Splits an Ultra-High-Definition (UHD) digital audio/video signal to one of two UHD HDMI displays or allows switching between two sources at one display
  • 4K@60Hz resolution, full 3D video and Deep Color
  • Top-mount push-button to switch between sources or displays
  • Supports video amplifier bandwidth up to 340 MHz and 3.4 Gbps per channel (10.2 Gbps total) for 4Kx2K displays
  • Supports 36-bit Deep Color (12-bits per channel) and sYCC Color Space
  • Supports compressed DTS-HD Master Audio, 7.1 surround sound, Dolby TrueHD, and uncompressed LPCM 8-channel audio
  • HDCP compliant
  • Works with PlayStation and Xbox game systems, Blu-ray players, set-top boxes, satellite receivers; also works to capture gameplay on screen
  • Plug and play
  • Gold-plated contacts for corrosion-free connections
  •
Download Product catalog
HDCP 2.0
CTS 1.4b
CE
FCC
RoHS
General
Source-to-splitter and splitter-to-display range: up to 5 m (16 ft.)
Toggle button positions: up (connects port 1), down (connects port 2)
Power consumption: 5 volts
Connections
One HDMI female (input/output)
Two HDMI female (output/input)
