EXT3-POE-XR-R

EXT3−POE−XR−R is a high−performance, extended−reach HDBaseT 3.0 receiver for 4K60Hz (4:4:4) HDMI, USB, Ethernet, RS−232, and IR signals and 2−way powering over twisted pair. The EXT3−POE−XR−R receiver receives the HDBaseT 3.0 signal and converts it back into the original input signals. It extends video signals up 100m (330ft) over CAT copper cables at up to 4K@60Hz (4:4:4) video resolution.

Contact to Seller
  • Uncompressed 4K@60Hz (4:4:4) HDMI extension
  • Bidirectional PoE (Power over Ethernet/HDBaseT)
  • Flexible USB 2.0 host & devices extension
  • 1Gbps Ethernet extension
  • Up to 100m (330ft) reach

Inputs
  • 1 HDBT: On an RJ–45 female connector

Outputs
  • 1 HDMI: On an HDMI female connector

Ports
  • 1 USB 2.0 Host: On a USB–B female connector
  • 3 USB 2.0 Device: On USB type–A female connectors
  • 1 1000BaseT Ethernet: On an RJ–45 female connector for LAN extension

USB Features
  • Integrated USB Hubs: 1

Extension Line
  • Reach: Up to 100m (330ft)
  • Note: When using Kramer HDBaseT cables
  • Standards Compliance: HDBaseT 3.0

Video
  • Max Data Rate: 18Gbps bandwidth (6Gbps per graphic channel)
  • Max Resolution: 4K@60Hz (4:4:4) 24bpp resolution
  • Content Protection: HDCP 2.3
  • HDMI Support: 4K as specified in HDMI 2.0b
