Galil 6-C Way Closed–Back Ceiling Speakers

The Galil 6-C is a closed-back ceiling speaker featuring a multi-tap power transformer with selectable 8Ω, 70V, and 100V settings. Designed for versatile installation, it supports direct 8Ω operation or distributed audio systems using 70V/100V configurations.

Contact to Seller
  • UL Listed
  • Woofer — 6.5” polypropylene cone
  • Tweeter — 0.5” Mylar dome
  • Impedance — 8Ω
  • Power Handling — 30W RMS, 80W Continuous
  • Transformer Taps — 70/100V
  • 2 Speakers (1 Pair)
Download Product catalog
DESCRIPTION 2-way closed-back ceiling speakers
FREQUENCY RESPONSE 80Hz to 20kHz @ −10dB, 95Hz to 20kHz @ ±3dB
WOOFER 6.5” (165mm) polypropylene with rubber surround
TWEETER 0.5” (13mm) Mylar dome
IMPEDANCE 8Ω (transformer tap in off position)
TRANSFORMER TAPS 70V – 3.7W/7.5W/15W/30W/Off (Lo−Z), 100V – 7.5W/15W/30W/Off (Lo−Z)
SENSITIVITY 87dB SPL, 1W @1m
MAX SPL Continuous: 100.7dB, peak: 103.7dB
POWER HANDLING 30W RMS, 80W continuous program
CROSSOVER FREQUENCY 9.2kHz
COVERAGE ANGLE 101°
DIRECTIVITY FACTOR (Q) 7.5 averaged 1kHz to 10kHz
DIRECTIVITY INDEX (DI) 8.6dB averaged 1kHz to 10kHz
