The KDS-100DEC is an advanced 4K@60Hz video decoder that receives and decodes video streams over IP networks via copper or fiber Ethernet cables. It also supports RS-232 and CEC signal transmission from the encoder over the network for seamless AV system control and integration.
- Outstanding end–user experience
- Ideal for large–scale deployments
- Low latency
- Open standard streaming to connect 3rd party
- Simple planning and rollout
| Inputs | 1 HDMI: On a female HDMI connector |
| Outputs |
1 HDMI: On a female HDMI connector 1 Balanced Audio: On a 5−pin terminal block connector |
| Ports |
1 Ethernet: On an RJ-45 connection 1 RS-232: On a 3–pin terminal block connector for control 1 RS-232: On a 3–pin terminal block connector for data 1 Fiber on an LC Connector: Standard: 1000BASE–SX, 1000BASE–LX |
| Network | 1GE IPv4 Multicast IGMPv2 RTP/RTCP Over UDP MPEG-TS |
| Video | Maximum Input/Output Resolution: 3840x2160@60Hz 4:4:4 |
| Video Streaming |
Open Standard: H.264 and H.265 Maximum Streaming Resolution: 3840x2160@60Hz 4:2:2 Bit Rate Range: 1- 60 Mbps Latency: Low latency, about 40 msec |
| Power |
PoE+: IEEE 802.3at on LAN (PoE) port Optional power adapter: 12 V DC, 5A. Unit has to be supplied by a power supply specified as a Limited Power Source (LPS) or PS2 source of supply |
| Environmental Conditions |
Operating Temperature: 0 to + 45°C (32 to + 113 °F), 10% to 90%, non–condensing Storage Temperature: –20 to +70°C (–4 to + 158 °F), 10% to 90%, non–condensing Humidity: 10% to 90%, non–condensing |
