This solution delivers an outstanding user experience with HDMI and USB-C connectivity, laptop charging, intuitive KM/KVM control, and configurable roaming. It supports large-scale video walls up to 16×16, 1-second switching, and up to 999 channels. Advanced management features include P3K Open API, an LCD configuration screen, and robust security. Its scalable design, plug-and-play compatibility with Netgear M4250 AVoIP switches, Kramer Control, and KDS-USB2, along with a comprehensive product range, enables cost-effective deployment across diverse applications.
- Outstanding end–user experience
- Ideal for large–scale deployments
- Robust security
- Simple planning and rollout
| Inputs |
1 HDMI: On a female HDMI connector 1 USB-C: On a female USB-C connector |
| Outputs | 1 HDMI: On a female HDMI connector |
| Ports |
2 Ethernet: On RJ–45 connectors 1 Balanced Audio: On a 5–pin terminal block connector 1 RS-232: On a 3−pin terminal block connector 1 IR: On a 3.5mm TRS connector |
| USB Features | Integrated USB Hubs: 2-layer USB hubs when connecting to KDS−DEC7 |
| Network |
Multicast through RTSP (Real Time Streaming Protocol): IGMP snooping non–blocking, Layer 2 Unicast Through RTSP (Real Time Streaming Protocol) Bit Rate Peak: 850Mbps, 4K average: 350Mbps, 1080p average: 250Mbps |
| Video |
Compression Standard: JPEG-based, private stream Max Resolution: 4K@30Hz 4:4:4 HDR 10: Up to 4K30 4:2:2 12 bit |
