The M4250-26G4F-PoE+ is a NETGEAR managed switch designed for 1Gb AVoIP deployments, featuring 40 PoE+ ports with a 960W power budget and 8 SFP+ ports. It comes preconfigured for KDS-7 encoders and decoders, offers flexible mounting, adjustable fan modes, a front status display, and easy web-based management with a dedicated AV interface.
- The NETGEAR M4250 series ranges from 8 to 48 ports with a variety of PoE+ and Ultra90 PoE++ options for 15.4W, 30W, 60W, 75W, and 90W AVoIP endpoints.
- Uplink options include 1G for audio installations or standalone video installations, as well as 10G uplinks for larger-scale video deployments.
- Also includes 12–port multi–gigabit Ethernet and 16–port 1G/10G fiber models for plug-and-play aggregation in a star topology.
- Designed for a clean integration with traditional, rack–mounted AV equipment.
- A second pair of rackmount ears allows the switches to be mounted recessed by 2 inches to allow for the cabling.
| Ports |
Auto-sensing RJ45 PoE 10/100/1000BASE-T: 40 ports PoE+ (960W) Auto-sensing SFP+ 1000/10GBASE-X: 8 1G Ports: 40; 10G Ports: 8 Console Ports: Serial RS−232 RJ45 (rear); USB−C (rear) Service Port (Out-of-band Ethernet): 1 x RJ45 10/100/1000BASE−T (rear) |
| Power |
Fixed Power Supply: 1 internal PSU (C14 inlet) with 1 on/off switch PoE+ Ports (802.3at) 40 PoE Budget @ 100-240V AC in: 960 Watts |
| Cooling | Fixed Fans: Side−to−side airflow |
| STANDARDS COMPLIANCE |
IEEE 802.3af (up to 15.4W per port) IEEE 802.3at (up to 30W per port) IEEE 802.3at Layer 2 (LLDP) method |
| Feature Support | PoE timer/schedule (week, days, hours) |
| Indication LEDs |
Per Port: Speed, Link, Activity, PoE Per Device: Power, Fan |
| General |
Physical Dimensions: 44cm x 43.2cm x 4cm (17.32" x 15.75" x 1.7") W,D,H Shipping Dimensions: 53.6cm x 46.6cm x 12.2cm (21.1" x 18.3" x 4.8") W,D,H Product Weight: 6.31kg (13.91lbs) |
| Product Dimensions | 44.00cm x 43.20cm x 4.00cm (17.32" x 17.01" x 1.57" ) W, D, H |
| Product Weight | 6.3kg (13.9lbs) approx |
