MC3-2HAo

MC3−2HAo is a high−performance two−port HDMI input card which is part of the compatible modular matrices multi−signal cards family. MC3−2HAo can flexibly occupy any of the matrix card slots and its output signals are independently switched by the modular matrix to any of the matrix output ports. The card dual analog audio ports enable, independently per port, audio de−embedding or embedding.

Contact to Seller
  • Max. Resolution — 4K@60Hz (4:4:4)
  • Selectable Embedded, De–embedded or ARC Analog Audio
Download Product catalog

Outputs
  • 2 HDMI: On female HDMI connectors

Ports
  • 2 Unbalanced Analog Audio: On 3.5mm mini jacks

Video
  • Max Data Rate: 18Gbps (6Gbps per graphics channel)
  • Max Resolution: 4K@60Hz (4:4:4)
  • HDMI Support: HDR 10, 3D, Deep Color, x.v.Color™, ARC, Dolby® TrueHD, Dolby Digital Plus, DTS–HD®, and 7.1 multi–channel audio

User Interface
  • Content Protection: HDCP 2.2/1.4 compliant

Power
  • Consumption: 5W

Regulatory Compliance (Standards Compliance)
  • Safety: CE
