MP-100UPI
MP-100UPI – 100W USB-C Power Injector is a compact USB-C power injection solution designed to deliver up to 100W of power with support for PD 3.0. It supports 4K@60Hz 4:4:4 video through DP Alt Mode and provides USB 3.2 Gen 2 data rates up to 10 Gbps. Its compact 54 × 20 × 80 mm design makes it suitable for professional AV and connectivity applications.
- PD 3.0 w/ 100Winjection.
- DP alt mode w/ 4K@60Hz 4:4:4video
- Up to 10 Gb USB 3.2 Gen 2 data rate.
- Firmware can be upgraded via USB-C
- USB-C input w/ locking hole
| Input | (1) USB-C |
| Output | (1) USB-C |
| Video | Input: Up to 4K@60Hz4:4:4Output: Up to4K@60Hz4:4:4 |
| USB | Data Rate: 10 Gbps Device Power: 5V 3A |
| PD Standard | PD 3.0 |
| Power Consumption | 1W(Exclude USBdeviceload) |
| Dimension | 54(W) x 20(H) x 80(D) mm |
| Net Weight | 130g |
| Operation Temperature | -5 ~ +55 °C |
| Storage Temperature | 25 ~ +70 °C |
| Relative Humidity | 10%~ 90% |
