MP-EXT-2
MP-EXT-2 is the USB-C to HDMI converter. This converter is designed to convert 4K@60Hz 4:4:4(max) DisplayPort alt mode signal over USB-C video input to 4K@60Hz 4:4:4(max) HDMI 2.0 video output. The USB-C input interface also supports USB 3.2 Gen1 data transfer, Gigabit LAN and 100W fast-charging power delivery.
- Input supports 4K@60Hz 4:4:4.
- Output supports HDMI 2.0, 4K@60Hz 4:4:4.
- HDCP 2.3/2.2/1.x support.
- USB-C input supports 100W USB Power Charging.
- 3x USB 3.2 Gen1 (5Gbps) device ports for USB peripherals such as USB cameras, keyboard, and mouse.
- Each USB device port can deliver up to 5V 1A (5W) power.
Video Input
| Input Connector | (1) USB-C |
| Input Resolution | Up to 4K@60Hz 4:4:4 |
| Video Output | |
| Output(1) HDMI | (1) Female type-A HDMI |
| HDMI Output Resolution | Up to 4K@60Hz 4:4:4 (18Gbps) |
| HDMI Standard | 2.0b |
| HDCP Version | 2.3/2.2/1.4 compliant |
| USB | |
| Connector(3) USB-A, (1) USB-C | |
| USB Standard | (3) USB-A: USB 3.2 Gen 1, 5V 1A External Power Supply (1) USB-C: USB 3.2 Gen 1, DisplayPort Alt mode, 100W PD |
| Ethernet | |
| Standard10/100/1000Base-T | |
| General | |
| Bandwidth18Gbps | |
| Operation Temperature | -5 ~ +55℃ |
| Storage Temperature | -25 ~ +70℃ |
| Relative Humility | 10% - 90% |
