MP-USB41-3.2

MP-USB41-3.2 support Auto , manually, RS232 control, TCP control to switch USB device to one USB host and can check every USB device’s current. It has two USB-C host and 2 USB-A host, one USB-C host can transport 100W max power to charge connected host, the other USB-C support to upgrade USB HUB.

Contact to Seller
  • Support USB 3.2 Gen2, 10Gbps, support switch to 5Gbps
  • Support front panel, GUI, and RS232, TCP, and GPIO control
  • USB devices shared 4.5A max current, compatible with most large-power cameras
  • 100W power support to charge the connected host
Download Product catalog

USB Host

Host Port (2)USB-C，(2)USB-B
USB Standard USB 3.2 Gen2

USB Device

Device Port (2)USB-A, (2)USB-C
USB Standard USB3.2 Gen2

Control

Control port (1)RS232, (1)TCP/IP，(1)GPIO
Control Connector (1)4-pin terminal block, (1)RJ45,(1) Buttons

General

Bandwidth 10 Gbps (supports switch to 5Gbps)
Operation Temperature -10 ~ +55℃
Storage Temperature 25 ~ +70℃
Relative Humility 10% - 90%
Power Supply DC 24V 6.5A
