RC-308 is a compact 8-button control keypad compatible with standard US, European, and UK 1-gang wall boxes. It supports PoE via a single LAN cable and works with Kramer Control or as a standalone room controller using K-Config to manage AV systems, screens, lighting, and shades. Multiple keypads can connect via K-NET for power and communication.
- 8 RGB–color, backlit buttons
- PoE acceptor
- Connectable to auxiliary KNET™ keypads
- Supported by all Kramer control platforms
| Inputs | 1 IR Sensor: For IR learning |
| Outputs |
2 IR: On 2−pin terminal block connectors 2 Relays: On 2−pin terminal block connectors (36V AC or DC, 2A, 60VAC maximum on non−inductive load) |
| Ports |
1 Ethernet: On an RJ−45 female connector for PoE, device configuration, control, and firmware upgrade 2 RS-232: On 3−pin terminal block connectors1 RS-485: On a 3−pin terminal block connector 1 K-NET: On a 4−pin terminal block connector 2 Relays: On 2−pin terminal block connectors (30V DC, 1A) |
| General | Default IP Settings: DHCP Enabled |
| Power | Source: PoE or 12V DC 2A power supply |
| Environmental Conditions | Operating Temperature: 0° to +40°C (32° to 104°F) |
| Enclosure | Size: 1-gang wall−plate |
| Accessories | Included with all versions: power adapter, tweezers for removing button caps, standard button label set |
| Product Dimensions |
UK: 8.60cm x 4.70cm x 8.60cm (3.39" x 1.85" x 3.39" ) W, D, H EU, UK: 8.60cm x 4.70cm x 8.60cm (3.39" x 1.85" x 3.39" ) W, D, H EU: 8.00cm x 4.70cm x 8.00cm (3.15" x 1.85" x 3.15" ) W, D, H US: 6.98cm x 4.70cm x 11.43cm (2.75" x 1.85" x 4.50" ) W, D, H |
| Product Weight |
UK: 0.1kg (0.2lbs) approx EU, UK: 0.1kg (0.2lbs) approx EU: 0.1kg (0.2lbs) approx US: 0.1kg (0.2lbs) approx |
| Shipping Dimensions | UK: 23.20cm x 13.60cm x 10.00cm (9.13" x 5.35" x 3.94" ) W, D, H EU, UK: 0.00cm x 0.00cm x 0.00cm (0.00" x 0.00" x 0.00" ) W, D, H EU: 23.20cm x 13.60cm x 10.00cm (9.13" x 5.35" x 3.94" ) W, D, H US: 23.20cm x 13.60cm x 10.00cm (9.13" x 5.35" x 3.94" ) W, D, H |
