TP-594Txr

TP−594Txr is a high-performance HDBaseT 2.0 transmitter that extends 4K@60Hz (4:4:4) HDR video, HDMI, Ethernet, RS-232, IR, ARC, and audio signals up to 100m over a single CAT cable, with support for audio embedding and ARC routing.

Contact to Seller
  • Up to 100m (330ft) at 4K@60Hz (4:4:4)
  • Compatible with standard HDBaseT 2.0 systems
  • ARC, Ethernet & control signal extension
  • Intelligent routing of digital/analog ARC & audio
  • PoE provider

Inputs
  • HDMI: On a female HDMI connector

Outputs
  • HDBT: On an RJ–45 connector
  • Optical (Digital Audio): On a TOSLINK® connector

Ports
  • Balanced Stereo Audio: On a 5–pin terminal block connector
  • Ethernet: On an RJ–45 female connector for device control and LAN extension
  • RS-232: On a 3–pin terminal block for serial link extension
  • IR : On a 3.5mm mini jack for IR extension

Extension Line
  • Compression: Low–level standard DSC compression for signals above 4K@60 (4:2:0)
  • 4K@60 (4:4:4) Range with Compression: Up to 100m (330ft)
  • 4K@60 (4:2:0) Range with No Compression: Up to 100m (330ft)
  • Full HD (1080p@60Hz) Range with No Compression: Up to 130m (430ft),

Video
  • ax Bandwidth with Compression: 17.95Gbps (5.98Gbps per graphic channel)
  • Max Bandwidth with No Compression: 10.2Gbps (3.4Gbps per graphic channel)
  • Max Resolution with Compression: 3840x2160@60Hz 4:4:4 24bpp

User Interface
  • Indicators: Active source detection, PoE status, HDBaseT link, and power LEDs
  • Rear Panel: DIP switches
